| Model |
Cisco CS-T10-TS-L-K9= |
| Product compatibility |
Cisco Room Kit Series, Cisco Room Series, Cisco Room Panorama Series, Cisco Board Series (Board S Series and Board Pro Series) |
| Software compatibility |
● RoomOS 9.14.3 or later |
| ● Microsoft Teams Rooms Console on Android (optimized hardware for Microsoft Teams Rooms compatibility) |
| Call-control compatibility |
● Hosted: Controlled by codec, Cisco Unified Communications Manager 10.5.2 or newer, Webex Cloud |
| ● Cloud: Webex Cloud |
| Native Cisco room booking |
● Integrates with O365, Exchange and Google Calendar through Webex Hybrid Calendar service (requires Webex activation) |
| ● Ad-hoc space reservation with a few taps |
| ● View all upcoming meetings from room calendar |
| ● Extend your meetings |
| ● Touchless booking inside the room with Webex Assistant |
| ● Meeting reminders with single tap extension |
| Third-party web applications |
● Supports the usage of persistent web apps enabling third-party experiences |
| ● Web apps running on Room Navigator get access to the meeting room sensors’ data and the Webex hybrid calendar to enhance custom integrations for wayfinding, room booking, and digital signage |
| Default components |
● Room Navigator touch panel |
| ● Table stand |
| Signaling protocols |
TCP/IP |
| Display |
● Capacitive touch LCD |
| ● 10.1-inch diagonal |
| ● Anti-glare and anti-fingerprint |
| Resolution |
1920 x 1200 |
| Memory |
4GB |
| Sensors |
● Measures temperature, humidity, and air quality (TVOC). This is combined with general noise, ambient noise, and reverberation time (RT60) for room acoustics originating from built-in sensors in the Cisco video endpoints |
| ● Sensor values are accessible from RoomOS cloud APIs, displayed on the Control Hub dashboard and can be extracted to Cisco Spaces, third-party analytics and workspace management tools |
| Language support |
English, Arabic, Catalan, Czech, Danish, Dutch, Finnish, French, German, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese-Brazilian, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian |
| Digital signage |
Configurable in Control Hub |
| Physical dimensions(H x L x D) |
● 2.8 x 9.53 x 6.42 in. (7.1 x 24.2 x 16.3 cm) |
| ● Maximum height in vertical position 5.2 in (13.2 cm) |
| ● Minimal height in lower position on the table: 3.85 in (9.77 cm) |
| Weight |
1.39lb (0.63kg) |
| Power |
● Power over Ethernet (PoE) 802.3af Class 0 |
| ● 100-240VAC, 0.5A max, 50/60Hz |
| ● Option to set up office hours for the Room Navigator helping with energy savings and extends the lifetime of the touchscreen where digital signage, booking, and wake-up on motion detection is activated. |
| Interfaces |
● 1x Ethernet (RJ-45) 100/1000 Mbps for LAN (external network) or direct pairing |
| ● 1x microUSB (service port) |
| ● 1x factory reset pinhole |
| Security |
● Secure management using HTTPS and SSH protocols |
| ● Password protection for IP administration |
| ● Standards-based media encryption on all back-ends (Secure Real-time Transport Protocol [SRTP], using AES-128-GCM or AES-256-GCM) |
| ● WPA3TM and WPA3-Enterprise with CCMP128 Wi-Fi ® security |
| ● Password protection to access administration |
| ● Network settings protection |
| ● Support for 802.1x authentication protocol (either when the device is paired directly or remotely with the video endpoint) |
| Registration |
● Room Navigator can be registered directly to a Cisco video device (via direct or remote pairing) or registered to the Webex Cloud (requires Room Navigator license) |
| ● Room Navigator can be paired with a Cisco video device or deployed as a standalone hardware for workspaces without Cisco video deployment. Learn more about using the Room Navigator as a standalone device |
| Administration |
● Centralized room and device management in Control Hub |
| ● Workspace insights on a per workspace level and single dashboard for all workspaces |
| ● Simple onboarding – PIN-based pairing with room device |
| Operating temperature and humidity |
● 0°C to 40°C (32°F to 104°F) ambient temperature |
| ● 10% to 90% Relative Humidity (RH) |
| Storage and transport temperature |
● -20°C to 60° (-4° to 140°F) at RH 10% to 90% (noncondensing) |
| Regulatory compliance and standards |
● Directive 2014/30/EU (EMC Directive) and Directive 2014/35/EU (Low-Voltage Directive) |
| ● Directive 2011/65/EU (RoHS) |
| ● Directive 2002/96/EU (WEEE) |
| ● NRTL approved (product safety) |
| ● EMC: EN 55032 – Class A, EN 55024 |
| ● Safety: EN 60950-1, EN 62479 |
| ● FCC CFR 47 Part 15B (EMC) – Class A |
