| Model |
NSa 2800 |
| Operating system |
SonicOS 8 |
| Interfaces |
16 x 1GbE, 3 x 10G SFP+, 2 x USB 3.0, 1 x Console, 1 x Mgmt. port |
| Storage |
128 GB M.2 SSD |
| Storage Expansion slot |
Có (hỗ trợ nâng cấp đến 512 GB) |
| Centralized Management |
NSM 3.0+, CLI, SSH, Web UI, REST APIs |
| Logical VLAN and tunnel interfaces (maximum) |
256 |
| SAML Single Sign-On Users |
40,000 |
| Access points supported (maximum) |
512 |
| Hiệu năng Firewall / VPN |
| Firewall inspection throughput |
8 Gbps |
| Threat Prevention throughput |
6 Gbps |
| Application inspection throughput |
7 Gbps |
| IPS throughput |
7 Gbps |
| Anti-malware inspection throughput |
6 Gbps |
| TLS/SSL inspection and decryption throughput |
1.8 Gbps |
| IPSec VPN throughput |
5.5 Gbps |
| Connections per second |
50,000 |
| Maximum Connections (SPI) |
2,000,000 |
| Maximum connections (DPI) |
1,000,000 |
| Maximum connections (TLS) |
150,000 |
| VPN và Zero Trust Network Access (ZTNA) |
| Site-to-site VPN tunnels |
2,000 |
| IPSec VPN clients (max) |
50 (tối đa 1,000) |
| SSL VPN licenses (max) |
2 (tối đa 500) |
| Encryption/Authentication |
DES, 3DES, AES (128/192/256-bit), MD5, SHA-1, Suite B |
| Key exchange |
Diffie-Hellman Groups 1, 2, 5, 14 |
| Route-based VPN |
RIP, OSPF, BGP |
| Certificate support |
Verisign, Thawte, Cybertrust, RSA Keon, Entrust, Microsoft CA, SCEP |
| VPN features |
Dead Peer Detection, DHCP over VPN, NAT Traversal, Redundant VPN Gateway, Route-based VPN |
| Global VPN client platforms supported |
Windows 10, 11 |
| NetExtender |
Windows, Linux |
| Mobile Connect |
iOS, macOS, Android |
| SonicWall Private Access powered by Cloud Secure Edge |
Có (trong gói "3&Free Loyalty Program") |
| Dịch vụ bảo mật |
| Deep Packet Inspection services |
Antivirus, Anti-Spyware, IPS, TLS Decryption |
| Content Filtering Service (CFS) |
Lọc URL dựa trên danh tiếng, từ khóa, IP/HTTP/HTTPS |
| Comprehensive Anti-Spam Service |
Có |
| Application Visualization |
Có |
| Application Control |
Có |
| Capture Advanced Threat Protection |
Có – phân tích sandbox trên đám mây |
| DNS Filtering |
Có |
| Mạng và giao thức |
| IP address assignment |
Static, DHCP, PPPoE, L2TP, PPTP, DHCP server/relay |
| NAT modes |
1:1, 1:nhiều, nhiều:1, PAT, NAT chồng IP, NAT động, Transparent mode |
| Routing protocols |
Static, RIP v1/v2, OSPF, BGP |
| QoS |
Ưu tiên băng thông, DSCP, 802.1e, kiểm soát tốc độ |
| Authentication |
LDAP, RADIUS, TACACS+, SAML SSO, NTLM, 2FA, CAC |
| Local user database |
1000 |
| VoIP |
SIP, H.323, hỗ trợ DPI, QoS chi tiết |
| Standards |
TCP/IP, UDP, ICMP, HTTP/HTTPS, IPSec, SNMP, DHCP, PPPoE, RADIUS, IEEE 802.3 |
| Certifications |
FCC Class A, CE, RoHS, VCCI, UL, cUL, CB, TUV/GS, WEEE, REACH (pending IPv6) |
| High availability |
Active/Passive với đồng bộ trạng thái (Stateful HA) |
| Phần cứng |
| Form factor |
1U Rack Mountable |
| Power supply |
90W |
| Maximum power consumption (W) |
52.8 W |
| Input Power |
100–240 VAC, 50–60 Hz, 4A |
| Total heat dissipation (BTU) |
180.01 BTU |
| Dimensions (Unit: cm) |
43 x 32.5 x 4.5 |
| Weight |
4.6 kg |
| WEEE weight |
4.8 kg |
| Shipping weight |
7.2 kg |
| Environment (Operating/Storage) |
0°C – 40°C / -40°C – 70°C |
| Humidity |
5–95% không ngưng tụ |
