| Model |
T125-W |
| Throughput 1 |
| UTM (full scan)2 |
510 Mbps |
| Firewall (IMIX) |
660 Mbps |
| VPN (IMIX) |
480 Mbps |
| HTTPS (IPS enabled, full scan) |
270 Mbps |
| Antivirus |
880 Mbps |
| IPS (full scan) |
725 Mbps |
| Firewall (UDP 1518) |
2.28 Gbps |
| VPN (UDP 1518) |
1.44 Gbps |
| Capacity |
| Processor |
MT7988A Quad-Core A73 at 1.1 GHz |
| Memory |
4 GB DDR4 (2 GB x 2) |
| Flash Memory |
4 MB QSPI NOR |
| Storage |
16 GB eMMC |
| Network Interfaces |
1 x 2.5 GbE, 4 x 1 GbE |
| I/O interfaces |
1 Serial/2 USB-A 3.2 |
| Concurrent connections |
3,850,000 |
| Concurrent connections (proxy) |
125,000 |
| New connections per second |
26,500 |
| VLANs |
Unrestricted |
| WSM licenses (incl) |
0 |
| EDR Core Sensors included |
5 |
| Wireless |
| Wireless radios |
Radio 1 (2.4 GHz)
Wi-Fi 7 2x2 802.11be/ax/b/g/n
Data rate up to 688 Mbps
Radio 2 (5 GHz)
Wi-Fi 7 3x3 802.11be/ax/ac/a/n
Data rate up to 4323 Mbps
|
| Wireless Antennas |
2 x 2 SMA external 2.4 GHz and 5 GHz antennas
1 x 1 SMA external 5 GHz antenna |
| VPN Tunnels |
| Branch Office VPN |
10 |
| Mobile VPN |
10 |
| Security Features |
| Firewall |
Stateful packet inspection, TLS decryption, proxy firewall |
| Application proxies |
HTTP, HTTPS, FTP, DNS, TCP/UDP, POP3S, SMTPS, IMAPS, and Explicit Proxy
IMAPS and Explicit Proxy |
| Threat protection |
DoS attacks, fragmented & malformed packets blended threats |
| Filtering options |
Browser Safe Search, Google for Business |
| VPN |
| Site to Site VPN |
IKEv2, IPSec, Policy and Route Based Tunnels, TLS hub and spoke |
| Remote Access VPN |
IKEv2, IPSec, L2TP, TLS |
| Visibility |
| Logging and notifications |
WatchGuard Cloud & Dimension, Syslog, SNMP v2/v3 |
| Reporting |
WatchGuard Cloud includes over 100 pre-defined reports, executive summary, and visibility tools |
| Certifications |
| Security |
Pending: CC, FIPS 140-2 |
| Safety |
NRTL/CB |
| Network |
IPv6 Ready Gold (routing) |
| Hazardous substance control |
WEEE, RoHS, REACH |
| Networking |
| SD-WAN |
Multi-wan failover, dynamic path selection,
jitter/loss/latency measurement |
| Dynamic Routing |
RIP, OSPF, BGP |
| High Availability |
Active/passive, active/active |
| QoS |
802.1Q, DSCP, IP Precedence |
| Traffic Management |
By policy or application |
| IP address assignment |
Static, DHCP (server, client, relay), PPPoE, DynDNS |
| NAT |
Static, dynamic, 1:1, IPSec traversal, policy- based |
| Link aggregation |
802.3ad dynamic, static, active/backup |
| Physical and Power Specifications |
| Product Dimensions |
9” x 8.25” x 1.7” (230x210x44mm) |
| Shipping Dimension |
12.2”x 9.8”x 3.9” (311x250x98 mm) |
| Product Weight |
T125: 2.92 lbs (2.07 kg)
T125-W: 3.11 lbs (2.17 kg) |
| Shipping Weight |
T125: 4.52 lbs (2.05 kg)
T125-W: 4.80 lbs (2.18 kg) |
| Power Consumption |
20 Watts (Max) |
| Power |
100-240 VAC Autosensing |
| Environment |
Operating |
Storage |
| Temperature |
32° F to 104° F
0° C to 40° C |
-40° F to 158° F
-40° C to 70° C |
| Relative Humidity |
10% to 85%
non-condensing |
10% to 85%
non-condensing |
| Altitude |
0 to 9,843 ft at 95° F
(3,000 m at 35° C) |
0 to 15,000 ft at 95° F
(4,570 m at 35° C) |
| MTBF |
846,422 hours |
